VP-NC5102FS-LWDX1 60 FPS CS Mount Smart Camera (Lens not included) – VodaSecure

Deprecated: Function create_function() is deprecated in /home/vodasecure/public_html/wp-content/themes/betheme/header-shop.php on line 103

Vantage Products

VP-NC5102FS-LWDX1 60 FPS CS Mount Smart Camera (Lens not included)

  • Vanadium Oxide Uncooled Focal Plane Detector
  • Advanced Passive Infrared thermal Technology
  • 3600 mtr. Maximum Detection Range
  • Dual Stream Supported
  • 2 Way Audio
  • Support Onboard SD Card up to 32GB
  • Pan Tilt Supported
Category:
Description
Parameter Specifications
Camera
Image Sensor Vanadium Oxide Uncooled Focal Plane Detector
Signal System PAL/NTSC
Effective Pixels 384 (H) × 288 (V)
Pixel Element Size 17mm
Response Waveband 8 ~ 14mm
NETD <80mk @25°C, F#=1.0)
Spatial Resolution 0.68 0.68
Lens (Focus) 40mm
Detection Range (Vehicle) 6900m
Detection Range (Human) 3600m
Identification Range (Vehicle) 2300m
Identification Range (Human) 1200m
Field Angle 7.3°x5.5°
F Value 1
Compression
Video compression H.264 / MJPEG
Video Bit Rate 32 Kbps ~ 16 Mbps
Audio compression G.711
Functions
Storage NAS
Intelligent Analysis Line crossing detection, region entrance, region exiting, loitering,intrusion detection, object removal, unattended baggage, parking, rapid motion, people gathering
Intelligent Alarm  Motion detection, network disconnect, IP conflict, storage exception
Protocols TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP(SNMP, HTTPS, SIP, FTP, SRTP, 802, 1X, Ipv6 optional)
General One Key Recovery, Anti-flicker, Dual Stream, Heartbeat, Watermark, Password Protection
PTZ
Structure  Die-cast aluminum housing with steel or aluminum alloy material
Rotate Speed Pan: 0.01°~60°/S, Tilt: 0.01°~30°/S
Rotate Angle Pan: 0°??360° endless, Tilt: ??40°??-75° Pan: 0°~360° endless, Tilt: +40°~-75°
Internal Encoder Support
Preset 80
Communication Protocol Compatible with Pelco D, Pelco P/DALI
Max. Load 15Kg
PTZ Weight 13Kg
Power AC24V
Serial Port RS-485
Interface
Communication Interface 1 RJ45 10M/100M Self-adaptive Ethernet interface
Video Output 1Vp-p composite output (75 Ω/BNC)
General
Power Requirement DC24V
Power Consumption Max.165W
Operating Temperature  -30°C to + 60°C
Operating Humidity 95% or less (non-condensing)
Dimension 600×429×331 mm
Weight 25kg
Certifications
Certifications UL, CE, FCC, RoHS
