VV-AC13M10P-3S34IRB1 1.3MP, 10X Array IR Night Vision Outdoor PTZ Camera (Copy) – VodaSecure

Deprecated: Function create_function() is deprecated in /home/vodasecure/public_html/wp-content/themes/betheme/header-shop.php on line 103

Vantage Products

VV-AC13M10P-3S34IRB1 1.3MP, 10X Array IR Night Vision Outdoor PTZ Camera (Copy)

  • 1.3 megapixel HD 960p resolution
  • 1/3” Progressive Scan Sensor
  • High performance IR cut mechanical filter for true
    day & night vision
  • Inbuilt IR LEDs for 50 mtr IR range
  • 3 megapixel 6 mm IR corrected lens
  • High performance SMART Array IR LEDs with intensit y control
  • Dual glass for zero IR diffusion and no fog
  • IP66 weather proof outdoor enclosure
Category:
Description
Parameter Specifications
Camera
Image  sensor 1/3″  Progressive Scan  Sensor
Signal System PAL/NTSC
Effective Pixels 1280 (H) × 960 (V)
Frequency 50 Hz (PAL) / 60 Hz (NTSC)
Horizontal  Resolution 1.3 Megapixel
Minimum Illumination Color : 0.01Lux @ F1.2, 0.015 lux @ F1.4, B&W: 0 Lux at IR on
Signal to Noise > 62 dB
Gain Control Auto
White Balance Auto (2000K to 10000K)
DNR Inbuilt  3D DNR (Digital Noise Reduction) circuit
Auto Iris DC Drive
Gamma Correction 0.45
Sync System Internal
Lens
Lens  Type 3 Megapixel  6mm IR corrected lens
Lens  Mount ɸ 14
Focus Fixed
Day/Night
Functionality
Day & Night True Day & Night  with ICR
IR Cut High performance Mechanical IR Cut Filter with auto  switch
IR Source High performance 4 nos.  SMART Array  IR LEDs with intensity
control
IR Range Up to 50 Mtrs
IR Life 40000 operation hours
Interface
Video Output 1 Analog  AHD Video output
Power Input Standard DC Jack
Electrical
Power Requirement (± 10%) 12 VDC ± 10%
Power Consumption Max 7 W with IR on
Environmental
Enclosure IP 66  Weather proof  outdoor enclosure
Mounting bracket External  mounting bracket included
Operating Temperature -20°C to + 60°C
Operating Humidity 95% or less (non-condensing)
Mechanical
Color White & Black
Dimensions 300 X 174 X 131 mm
Weight 0.95kg
Certifications
Certifications  CE, FCC, RoHS
